Product Name:1450mm Diam 80mm Glass 100w Co2 Laser Tube

Product Details:
Model:
BL-100
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Piece/Pieces
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Shenzhen,Hongkong,Shanghai
Payment Terms:
L/C ,T/T,Western Union,MoneyGram,Other
Show Buyers your Ability to Supply:
Production Capacity:
1000000 Piece/Pieces per Year
Delivery Time:
Within 3 days after payment, except the customized items.
Packaging:
1450mm Diam 80mm Glass 100w Co2 Laser Tube professional packings: Inner packing is in respective carton boxes with foam, the outer packing is in wooden cases with foam or as the customer's requirement

Detailed Product Description:

banner3-2

1450mm Diam 80mm Glass 100w Co2 Laser Tube



We manufacture glass sealed 100w co2 laser tubes from 30W to 150W for both medical and industrial use with high quality.



Application: Industrial engraving, cutting and medical usage.
Applicable materials: leather, cloth, glass, stone, acrylic wood, colore board, ect.
Applicable industry: advertising decoration, gifts, paper products, bamboo products, lighting, package, etc.



Our prices are competitive & our 100w laser tubes are our patented products of high quality!

Best Manufactory & Hottest Sale 100w Co2 Laser Tubes + Warranty for 3 months!



Specification & Parameters of Co2 100w Laser Tubes

Model

100W

Length

1450mm

Pipe Diameter

80±1mm

Type of Cooling

Water-cooling 15-25°C

Impulse Frequency

100% to 5KHZ

Weight

5Kg

Outer Packing

25*25*1650mm

Wavelength

10.6um

Mode of Excitation

Electric excitation

Beam polarization mode

Linear reasonably

Beam Divergence Angle

3.1mrad

Light Beam Quality

≤1.1

Stability

10%

Lasing Mode

Much lower order film

Output Power Stable Value

100W

Max Output Power

115W

Starter Voltage

30KV

Working Voltage

20KV

Starter Current

5.0mA

Max Working Current

32mA

Spot Diameter

5±1 mm

N.B. Subject to changes without prior notice.



Bill Laser Co2 100w Laser Tubes Products




Bill Laser Co2 100w Laser Tubes Production Center

Factory Workshop

ALLA 600.jpg

ALL A 600.jpg



Bill Laser Co2 100w Laser Tubes Professional Packings

Packaging A600.jpgA600.jpg



Bill Laser Co2 100w Laser Tubes & Other Laser Products

ALL_A600

A600

A600



Bill Laser Devices Co., Ltd. 2013 Tendency

Letter of Invitation

From 25th to 28th Feb., 2013, we are attending a Trade Show in Pazhou, Guangzhou.

Our Booth is No. B28 located in 1st / Floor.
Welcome your visiting!



From 1st to 4th March, 2013, we are attending the 2nd Trade Show in Pazhou, Guangzhou.
Our Booth is No. Q45b, will be located in Level No.1, Hall No.11.1.
Welcome your visiting & You will be our distinguished guests!



Bill Laser Devices Co., Ltd. Recent Honors

Bill Laser AwardsAlibaba Gold Supplier



CO2 Laser Tubes Working Common Problems:



1. Low efficiency of output power:

  1. Check whether the output mirror surface of the laser tube may have nick and dirt or the stand point may be placed in wrong position.
  2. Check the output current, supply power, the temperature and flow of cooling water and the cleanness of water.
  3. Check the cleanness of the focus lens and the reflectivity mirror, whether they fever or divert light way in the operation.

2. Spark in high voltage:

  1. Check whether there is sundry around the joints high voltage or the tube is too close to metal.
  2. Indoor environment might be too humid to cause conductive phenomenon. Please pay attention to water when using cooling water machine in summer.
  3. Check whether the high voltage’s inner connections of the power supply to appear to be broken and destroyed.

3. Laser tubes broken and the laser heads fallen off:

  1. Water temperature should be controlled in the range of 15 to 25 degrees. The cooling water can’t be frozen in frigid area and be left within the laser tube under 0 degree.
  2. The tube must be operated in the condition of water provided. (To test the tube light or not with water offered)
  3. To check the cooling water tube whether has appeared cracked.
  4. To check whether there is bubble in the tube.
  5. To check if the water current is normal and the outlet is in accordance with the principle--“down in up out”.
  6. The analyses abovementioned, the products can’t have guarantee after-sale service.

We are now looking for companies seeking agents all over the world!



Please Contact Allison



We are the manufacturer of 1450mm glass 100w Co2 Glass Laser Tubes, Co2 Laser Products, customizing is also available here!



Bill Laser, the manufacturer of 1450mm glass 100w Co2 Laser Tubes, your perfect expert of all Laser Parts.



Thanks for your attention of Bill Laser Devices Co., Ltd. We honor to serve and honor our clients.

If you are interested in any item of our products, please contact us with no hesitation.

Welcome your inquiry!
